תיאור
מיקסר גדול המיועד להופעות וכולל 16 ערוצי מיקרופון (XLR) או כלי נגינה (PL) ו-4 ערוצי סטריאו לחיבור כלי נגינה סטריאופוניים כמו קלידים או מחשב.
כל ערוץ מיקרופון כולל אקוולייזר (EQ) בעל 3 תחומי תדרים ותדר אמצעי שניתן לכיוון, פילטר Low cut למיקסר 4 שלוחות המאפשרות שליטה על כמה ערוצים
מפיידר אחד ו4 שליחות ל-4 מיקסים נפרדים (AUX), שתיים מהן משמשות גם כשליחות ל-2 מולטי אפקטים איכותיים בעלי 99 תוכניות.
המיקסר כולל אקוולייזר (EQ) גרפי על היציאה הראשית והוא בעל 9 תחומי תדר ומשלב מערכת לזיהוי פידבקים
למיקסר יש כניסת ויציאת TAPE לחיבור נגן מדיה או מקליט חיצוני (מצלמת וידאו לדוגמא) בחיבור RCA.
מידע נוסף
- Premium ultra-low noise, high-headroom analog mixer
- 16 state-of-the-art XENYX Mic Preamps comparable to stand-alone boutique preamps
- Neo-classic "British" 3-band EQs with semi-parametric mid band for warm and musical sound
- 2 independent studio-grade 24-bit stereo FX processors with 99 awesome presets including reverb, chorus, flanger, delay, pitch shifter and various multi-effects
- High-precision 9-band stereo graphic EQ allows precise frequency correction of monitor or main mixes
- Revolutionary FBQ Feedback Detection system instantly reveals critical frequencies
- Peak LEDs, Mute, Main mix and subgroup routing switches, Solo and PFL functions on all channels
- 2 fully featured stereo input channels with 4-band EQ plus 2 additional stereo input channels with Level and pre-fader Aux controls
- Inserts on each mono channel and main mix for flexible connection of outboard equipment
- 4 Subgroup outputs and additional Mono output with sweepable Low Pass filter for subwoofer application
- 4 Aux sends per channel: 2 pre/post fader switchable for monitoring/FX applications, 2 post fader (for internal FX or as external send)
- Balanced Main mix outputs with ¼" jack and gold-plated XLR connectors, separate Control room, Headphone and stereo Tape outputs
- Solo-In-Place and Pre-Fader-Listen functions plus full-featured Talkback section
- Standby switch mutes all channels during breaks while background music is provided via CD/Tape inputs
- Long-wearing 60 mm logarithmic-taper faders and sealed rotary controls
- Internal autorange power supply for maximum flexibility (100 – 240 V~), noise-free audio, superior transient response plus low power consumption for energy saving
מאפייני מוצר
- כניסות 16X XLR 16X TRS (PL) 4X TRS Stereo 1X RCA
- אפקט מובנה
- משקל בק"ג 8.6
- עומק במ"מ 410
- 16 ערוצי סטריאו
- יציאה Main-Out: XLR × 2 Main-Out: TRS Stereo × 1 Sub Groups: TRS Stereo × 2 RCA × 1
- פיידר
- רוחב במ"מ 682
- גובה במ"מ 100
